Model NO.: | ZD-REBAR | Standard: | ASTM |
---|---|---|---|
Material: | HRB335/HRB400/HRB500/Hrb600 | Custom Made: | Yes |
Custom Cycle: | 7-15 Days | Production Standards: | ASTM/JIS/AISI/DIN/BS/En/GB |
Payment Term: | 30%T/T Advance + 70% Balance | Alloy Or Not: | Low Alloy |
MOQ: | 3tons | Lengh: | Customized |
Advantage: | Wear Resistance, Machinability, Easy Welding | Specification2: | Zd-Hrr4 5 6 8 10 |
Specification3: | Zd-Hrr12 13 14 15 16 18 20 | Standard1: | ASTM A 6/a 6m-07 BS 4-1:1993 En 10024 JIS G 3192 |
Transport Package: | Export Standard Package/as Request | Specification: | According To Customer Requirements |
Trademark: | ZHENGDE | Origin: | China |
HS Code: | 7214200000 | Supply Ability: | 155000 Tons/Month |
Highlight: | hrb400 steel rebar,hrb400 steel reinforcement rebar,astm steel rebar |
Steel bars are widely used in the field of construction. In the design of concrete structures, steel bars are often used to strengthen concrete members, and exert their advantages of strength and toughness in the process of stress. In addition, steel bars are also used to manufacture components in reinforced concrete structures such as concrete piles and foundation caps, which can make the entire building structure stronger and more stable.
d mm |
weight kg/m |
4.25d mm |
cm2 | Rebar type/d | |||||||||
1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | ||||
10 | 0.616 | 43 | 0.785 | 1.570 | 2.355 | 3.140 | 3.925 | 4.710 | 5.495 | 6.280 | 7.065 | 7.850 | HRB335/10 |
12 | 0.888 | 51 | 1.131 | 2.262 | 3.393 | 4.524 | 5.655 | 6.786 | 7.917 | 9.048 | 10.179 | 11.310 | HRB335/12 |
14 | 1.208 | 60 | 1.539 | 3.078 | 4.617 | 6.156 | 7.695 | 9.234 | 10.773 | 12.312 | 13.851 | 15.390 | HRB335/14 |
16 | 1.578 | 68 | 2.011 | 4.022 | 6.033 | 8.044 | 10.055 | 12.066 | 14.077 | 16.088 | 18.099 | 20.110 | HRB335/16 |
18 | 1.998 | 77 | 2.545 | 5.090 | 7.635 | 10.180 | 12.725 | 15.270 | 17.815 | 20.360 | 22.905 | 25.450 | HRB335/18 |
20 | 2.466 | 85 | 3.142 | 6.284 | 9.426 | 12.568 | 15.710 | 18.852 | 21.994 | 25.136 | 28.278 | 31.420 | HRB335/20 |
22 | 2.984 | 94 | 3.801 | 7.602 | 11.403 | 15.204 | 19.005 | 22.806 | 26.607 | 30.408 | 34.209 | 38.010 | HRB335/22 |
25 | 3.853 | 106 | 4.909 | 9.818 | 14.727 | 19.636 | 24.545 | 29.454 | 34.363 | 39.272 | 44.181 | 49.090 | HRB335/25 |
28 | 4.834 | 119 | 6.158 | 12.316 | 18.474 | 24.632 | 30.790 | 36.948 | 43.106 | 49.264 | 55.422 | 61.580 | HRB335/28 |
32 | 6.313 | 136 | 8.042 | 16.084 | 24.126 | 32.168 | 40.210 | 48.252 | 56.294 | 64.336 | 72.378 | 80.420 | HRB335/32 |
36 | 7.990 | 153 | 10.179 | 20.358 | 30.537 | 40.716 | 50.895 | 61.074 | 71.253 | 81.432 | 91.611 | 101.790 | HRB335/36 |
40 | 9.865 | 170 | 12.566 | 25.132 | 37.698 | 50.264 | 62.830 | 75.396 | 87.962 | 100.528 | 113.094 | 125.660 | HRB335/40 |
45 | 12.485 | 191 | 15.904 | 31.808 | 47.712 | 63.616 | 79.520 | 95.424 | 111.328 | 127.232 | 143.136 | 159.040 | HRB335/45 |
50 | 15.413 | 213 | 19.635 | 39.270 | 58.905 | 78.540 | 98.175 | 117.810 | 137.445 | 157.080 | 176.715 | 196.350 | HRB335/50 |
55 | 18.652 | 234 | 23.758 | 47.516 | 71.274 | 95.032 | 118.790 | 142.548 | 166.306 | 190.064 | 213.822 | 237.580 | HRB335/55 |
60 | 22.192 | 255 | 28.274 | 56.548 | 84.822 | 113.096 | 141.370 | 169.644 | 197.918 | 226.192 | 254.466 | 282.740 | HRB335/60 |
70 | 30.206 | 298 | 38.485 | 76.970 | 115.455 | 153.940 | 192.425 | 230.910 | 269.395 | 307.880 | 346.365 | 384.850 | HRB335/70 |
80 | 39.462 | 340 | 50.265 | 100.530 | 150.795 | 201.060 | 251.325 | 301.590 | 351.855 | 402.120 | 452.385 | 502.650 | HRB335/80 |
90 | 49.942 | 383 | 63.617 | 127.234 | 190.851 | 254.468 | 318.085 | 381.702 | 445.319 | 508.936 | 572.553 | 636.170 | HRB335/90 |
Shandong Zhengde Metal Manufacturing Co., Ltd. is a production and sales company integrating hot-rolled steel coils, cold-rolled steel coils, galvanized steel coils, color-coated steel coils, section steel, steel pipes, steel wires, metal mesh, stainless steel, aluminum, copper and other metal products integrated large enterprises. Five production and sales bases have been formed in Binzhou, Liaocheng, Wuxi, Tianjin, Jinan and Tai'an, with more than 100 production lines, 4 nationally recognized laboratories, 2 technical engineering centers, and 5 enterprise technology centers. Products are exported to more than 50 countries and regions such as North America, South America, Europe, Africa, Oceania, Middle East, and Southeast Asia.
