Model NO.: | ZD-HRSWR | Application: | Rope, Packaging, Netting, Manufacturing, Fencing, Construction |
---|---|---|---|
Alloy Or Not: | Custom Made | Standard: | BS, JIS, GB, ASTM, DIN, AISI |
Material: | ASTM A36 A572 A992 S235jr/J0/J2 S355jr/J0/J2 | Custom Made: | Yes |
Custom Cycle: | 7-15 Days | Product Name: | Steel Wire Rod |
Payment Term: | 30%T/T Advance + 70% Balance | MOQ: | 3tons |
Lengh: | Custom Made | Advantage: | Wear Resistance, Machinability, Easy Welding |
Specification2: | Zd-Hrswr5 6 7 8 9 10 | Specification3: | Zd-Hrswr12 14 15 16 18 |
Standard1: | ASTM A 6/a 6m-07 BS 4-1:1993 En 10024 JIS G 3192 | Transport Package: | Export Standard Package/as Request |
Specification: | According To Customer Requirements | Trademark: | ZHENGDE |
Origin: | China | HS Code: | 7213100000 |
Supply Ability: | 50000 Tons/Month | ||
Highlight: | Q195 high carbon steel wire,0.4mm high carbon steel wire,Q235 high carbon steel cable |
Zhengde Steel wire rod(s) is also called wire rod, which usually refers to small-diameter round steel in a coil. The diameter of the wire rod is in the range of 5-19mm (usually 6-9mm), and the lower limit is the minimum size of the hot-rolled steel section. There are many varieties of wire rods. Low carbon steel wire rods in carbon steel wire rod(s) are commonly called soft wires, and medium and high carbon steel wire rods are commonly called hard wires. Wire rods are mainly used as blanks for wire drawing, and can also be directly used as building materials and processed into mechanical parts. Stainless steel wire rod(s) are used in the manufacture of stainless steel wire, stainless steel spring steel wire, stainless upset forging steel wire and steel wire for stainless steel wire rope. With the advancement of production technology, wire rods with square, hexagonal, fan-shaped and other special-shaped sections have appeared; the upper limit of diameter has been expanded to 38 mm; the weight of the coil has increased from the original 40-60 kg to 3000 kg. Due to the development of a new post-rolling heat treatment process, the iron oxide scale on the surface of the wire rod has been significantly thinned, and the structure and performance have also been greatly improved.
OD(mm) | Area(mm²) | Weight(kg/m) | L(m) | Weight(kg/s) |
Φ5.5 | 23.8 | 0.187 | 1000 | 187 |
Φ6 | 28.3 | 0.222 | 1000 | 222 |
Φ6.5 | 33.2 | 0.26 | 1000 | 260 |
Φ7 | 38.5 | 0.302 | 1000 | 302 |
Φ7.5 | 44.2 | 0.347 | 1000 | 347 |
Φ8 | 50.3 | 0.395 | 1000 | 395 |
Φ8.5 | 56.7 | 0.445 | 1000 | 445 |
Φ9 | 63.6 | 0.499 | 1000 | 499 |
Φ9.5 | 70.9 | 0.556 | 1000 | 556 |
Φ10 | 78.5 | 0.617 | 1000 | 617 |
Φ10.5 | 86.6 | 0.69 | 1000 | 690 |
Φ11 | 95 | 0.746 | 1000 | 746 |
Φ11.5 | 104 | 0.815 | 1000 | 815 |
Φ12 | 113 | 0.888 | 1000 | 888 |
Φ12.5 | 123 | 0.963 | 1000 | 963 |
Φ13 | 133 | 1.04 | 1000 | 1040 |
Φ13.5 | 143 | 1.12 | 1000 | 1120 |
Φ14 | 154 | 1.21 | 1000 | 1210 |
Φ14.5 | 165 | 1.3 | 1000 | 1300 |
Φ15 | 177 | 1.39 | 1000 | 1390 |
Φ15.5 | 189 | 1.48 | 1000 | 1480 |
Φ16 | 201 | 1.58 | 1000 | 1580 |
Φ17 | 227 | 1.78 | 1000 | 1780 |
Φ18 | 254 | 2 | 1000 | 2000 |
Φ19 | 284 | 2.23 | 1000 | 2230 |
Shandong Zhengde Metal Manufacturing Co., Ltd. is a production and sales company integrating hot-rolled steel coils, cold-rolled steel coils, galvanized steel coils, color-coated steel coils, section steel, steel pipes, steel wires, metal mesh, stainless steel, aluminum, copper and other metal products integrated large enterprises. Five production and sales bases have been formed in Binzhou, Liaocheng, Wuxi, Tianjin, Jinan and Tai'an, with more than 100 production lines, 4 nationally recognized laboratories, 2 technical engineering centers, and 5 enterprise technology centers. Products are exported to more than 50 countries and regions such as North America, South America, Europe, Middle East region, Russia, Africa, North America, and other parts of the world.
